radar reflector - passive - EM12 Ball Reflector
AM012
Lieferung ohne Halter
Delivered without mounting bracket
AM012RM
Echomax now offer the EM12 a popular corner 12 inch ball reflector, for everyday, emergency or liferaft use. The RORC recommend a mounting height of 4 metres above sea level or on small craft as high as possible. Mount in the catch rain position with the open corners facing the horizon. Mounting heights of 10-35 feet will give an approximate radar response between 4-7 nautical miles. In the catch rain position the EM12 gives a maximum RCS of 5.57 m² and an average RCS of
1.77 m².
• Meets ISAF rules 2015 and on USCG approved radar reflector list
• Optional extras: (sold separately)
• P.V.C 6” 1/14 TPI - adapter fits all VHF-GPS fittings
• Flange mount for direct cabin roof mount.
• Sailboat use: suspend from rigging in catch rain position.
• Supplied as a flat pack for quick assembly and immediate use.
• Packed dimensions are 13” x 13” and weighs just 730 g
1.77 m².
• Meets ISAF rules 2015 and on USCG approved radar reflector list
• Optional extras: (sold separately)
• P.V.C 6” 1/14 TPI - adapter fits all VHF-GPS fittings
• Flange mount for direct cabin roof mount.
• Sailboat use: suspend from rigging in catch rain position.
• Supplied as a flat pack for quick assembly and immediate use.
• Packed dimensions are 13” x 13” and weighs just 730 g
*) For mounting an antenna base or a deck socket required.
